Intelligent Climate Controller K9

Input section

[3 channels] High-precision temperature sensor, configurable for outdoor temperature;

[2 channels] 4-20mA signal humidity sensor or CO2 sensor or NH3 sensor;

[1 channel] 12V battery input interface, can be configured as outage alarm;

Output section

[3 channels ] 0-10V analog signal, can be configured as pressure adjusting model, variable frequency fan, air inlet, etc;

[8 channels ] Relay output, configured as fan, cooling pad water pump, heater, switch, 2 channels air inlet, etc;

[ 1 channel ] Relay alarm signal;

[ 1 channel ] Inlay relay RS485,gather product data;

Communication section

[1 channel] RS485 communication, can be configured as IoT, 1 channel electricity meter, water meter, pulse;
