Intelligent Climate Controller Future 100

Input section

[7 channels] High-precision temperature sensor, 6 channels of indoor temperature and 1 channel of outdoor temperature can be configured;

[6 channels] 4-20mA signal sensor, which can be configured as temperature, humidity, CO2, NH3, H2S, static pressure, wind speed, etc.;

[2 channels] 0-5V analog quantity, can be configured as feedback signal of wind window and curtain position;

[7 channels] Relay, feed and water consumption, external alarm signal, etc; [1 channel] 12V battery input interface; configured as outage alarm;

Output section

[3 channels] 0-10V analog quantity, can be configured as up to 3 channels of variable speed fans, 2 channels of air inlet (shared) and 1 channel of light adjustment;

[16 channels] Relay, can be configured as fixed speed fan, cooling pad water pump, spray, heater, circulating fan, timer, temperature control switch, wind window, curtain, alarm;

Communication section

[2 channels] RS485 communication interface, can be configured as communication sensors, electricity meters, water meters, Internet of Things and expansion;
